Shoebox Area Light — 100/120/150W selectable | Up to 21000 lm | 120-277V | 3000/4000/5000K selectable CCT | 0-10V dimmable | DLC, ETL
80–600 W platforms with field-selectable wattage and CCT options.
| Wattage Range | 100–300W |
| Lumen Output | 14,000–42,000 lm |
| Efficacy | 140 |
| CCT Options | 3K / 4K / 5K (selectable) |
| CRI | 80 |
| Voltage | 120-277 |
| Dimming / Controls | 0-10 |
| IP Rating | IP65 |
| Finish | Bronze |
| Certifications | DLC, ETL, 10-YR Warranty |
| Warranty | 10-year non-prorated |
| US Stock | 4 configurations · $200M+ inventory |
Shoebox Area Light — 100/120/150W selectable | Up to 21000 lm | 120-277V | 3000/4000/5000K selectable CCT | 0-10V dimmable | DLC, ETL
Every number on this page comes off the specification sheet and the PIM record behind it. Download the full PDF for complete photometric data, wiring diagrams, and mounting details.
| Model | Watts | Lumens | CCT | Voltage | Image |
|---|---|---|---|---|---|
| ECO-J-AR08-150WBT3DA2 -BR10S | 100–150W | 14,000–21,000 | 3K/4K/5K | 120-277 | |
| ECO-J-AR08-150WBT3DA2 -BR3N10S with photocell base | 100–150W | 14,000–21,000 | 3K/4K/5K | 120-277 |  |
| ECO-J-AR08-300WBT3DA2 -BR10S | 200–300W | 28,000–42,000 | 3K/4K/5K | 120-277 |  |
| ECO-J-AR08-300WBT3DA2 -BR3N10S with photocell base | 200–300W | 28,000–42,000 | 3K/4K/5K | 120-277 |  |
